| Type |
ITEM No. |
Color |
Specific
Gravity
(g/cm3) |
Hardness
(shore A) |
Tensile
Strength
(Mpa) |
Elongation
at Break
(%) |
TEARING STRENGTH (KN/m) |
Temperature Range
(°C) |
Thickness (mm) |
Width (meter) |
| Silicone Rubber |
6006250 |
Transparent |
1.2±0.05 |
60±5 |
>6 |
>250 |
>15 |
-50~200 |
2~25 |
1~1.5 |
| High Tearing Silicone Rubber |
6006450 |
Transparent |
1.2±0.05 |
60±5 |
>6.5 |
>450 |
>26 |
-50~200 |
2~10 |
1.2~4 |
| Super Tearing Silicone Rubber |
6009650 |
Transparent |
1.2±0.05 |
60±5 |
>9 |
>650 |
>32 |
-50~200 |
0.6~2 |
1.2~6 |
Over 10mm thickness-Plates : 2500mm x 1000-2000 mm
8mm & 10mm – Rolls: 1000mm-1200mm wide x 5-10 meters long
1mm to 6mm - Rolls: 1000mm -1200mm-4000mm wide x 10-20 meters long
Maximum width 6000mm
Available in thicknesses: 1mm to 25mm
OTHER COLOURS, HARDNESS AND TECHNICAL SPECIFICATIONS CAN BE AVAILABLE UPON REQUEST
Information of a technical nature is based on laboratory tests which either Meridian conducts or sends to an independent laboratory for testing for determination of uses as requested in writing by customer. Meridian believes these to be reliable. However, Meridian has no control over the application of the material to, or part of, the final product and therefore, Meridian makes no express or implied warranty of result, fitness or merchantability. The customer should determine reliability for the end use or particular application.
